Ultra-Low Power Technology

 1.6 V to 5.5 V operation from a single supply

 Stop (RAM retained): 0.23 µA, (LVD enabled): 0.31

µA

 Snooze: 0.70 mA (UART), 1.20 mA (ADC)

 Operating: 66 µA/MHz

16-bit RL78 CPU Core

 Delivers 41 DMIPS at maximum operating frequency

of 32 MHz

 Instruction Execution: 86% of instructions can be

executed in 1 to 2 clock cycles

 CISC Architecture (Harvard) with 3-stage pipeline

 Multiply Signed & Unsigned: 16 x 16 to 32-bit result in

1 clock cycle

 MAC: 16 x 16 to 32-bit result in 2 clock cycles

 16-bit barrel shifter for shift & rotate in 1 clock cycle

 1-wire on-chip debug function

Main Flash Memory

 Density: 48 KB to 64 KB

 Block size: 1 KB

 On-chip single voltage flash memory with protection

from block erase/writing

 Self-programming with secure boot swap function

and flash shield window function

Data Flash Memory

 Data Flash with background operation

 Data flash size: 4 KB

 Erase Cycles: 1 Million (typ.)

 Erase/programming voltage: 1.8 V to 5.5 V

RAM

 4 KB size

 Supports operands or instructions

 Back-up retention in all modes
